詳細說明
型號規格 | WBP12-10 030504094 | WBP12-20 030506094 | WBP18-10 030504132 | WBP18-20 030506132 | |||
額定載荷 | kg | 450 | 680 | 450 | 680 | ||
臺面最低高度 | mm | 635 | 870 | ||||
總提升高度 | mm | 940 | 1320 | ||||
平臺尺寸 | mm | 760x510x50 | 915x610x50 | 960x510x50 | 915x610x50 | ||
輪子直徑 | mm | Ф125 | |||||
輪子材料 | 聚氨脂 Polyurethane | ||||||
20”柜裝箱重 | Pcs | 84 | 54 | 52 | 36 | ||
包裝尺寸 | mm | 860x530x650 | 1020x630x650 | 860x530x870 | 1020x630x870 | ||
凈重 | kg | 80 | 101 | 82 | 118 | ||
